用途与特点：
◆气动隔膜泵供墨；
◆传动齿轮采用循环润滑供油系统减低噪音，延长齿轮工作寿命，同时提高套色准确度。
◆设有自动刹车机构，机组分离后，刹车机构锁紧周向位移，保持印刷机位。
◆本机有单色、双色、三色、四色可供用户选择。
◆45#钢高频精磨齿轮，印刷更精确，效果更清晰。
◆本机胶轴网纹采用广东著名厂家生产。
◆配变频主动电机，起步稳，低噪音，节电可达25%。
Features:
◆Device ink from pneumatic Diaphragm.
◆Gear transmission uses circulating lubrication oil supply system to minimize noise and extend service life of gear and improve the precision of chromatic printing.
◆With automatic braking mechanish when the fight crew separate the brake locking keep printed seats.
◆The machine has single-color,double-color,three-colorand four-color available for option.
◆Main gear driving adopts 45# good steel to make.And gear to quench to deal.
◆The rubber-axis, reticulate, and other components used in machine are well-known manufacturers in Guangdong.
◆Frequency adjustment of motor starting stability,low noise,energy saving 25%.
技术参数 Technological Parameter:
|
型号Model
|
滚筒直径(mm)
Roller diameter
|
过纸宽度(mm)
Over the paper width
|
有效印刷面积(mm2)
Area of valid printing
|
整机重量(约kg)
Whole machine weight
|
电机功率(kw)
Elecdtrical power
|
|
TS-1900
|
800
|
1800
|
2500×1600
|
7500
|
7.5
|
|
TS-2100
|
800
|
2000
|
2500×1800
|
8000
|
7.5
|
|
TS-1900
|
908
|
1800
|
2850×1600
|
8500
|
10
|
|
TS-2100
|
908
|
2000
|
2850×1800
|
9000
|
10
|
本印刷机型号由1900到3000均可定做。 This printing machine model number be arrived by 1900 to 3000 all can make to order. |
